FPD Panel

Post by haricots » Mon Aug 25, 2008 2:47 pm

So I want to make my own 1/8" <> 1/4" MOTM panel but I need to confirm measurements with others who have done this. Obviously I'm using Front Panel Designer to do this. My question is what radius should I user for the

1) mounting screw holes
2) 1/8" sockets
3) 1/4" sockets

Thanks again.

-=john

User avatar
consumed
International Filter Conspiracy
Posts: 3697
Joined: Fri May 25, 2007 1:38 pm
Location: nor cal

Post by consumed » Mon Aug 25, 2008 3:20 pm

i would really recommend that you:

1. buy a cheap pocket slide caliper. i got mine for less than $10.
a caliper allows you to measure diameters inside and out relatively precisely.
it looks kinda like this one:


2. buy your hardware and hold it in your hand before you design the panel!
3. measure your hardware with the caliper to get *exact* sizing so there is no confusion. front panels are too expensive to make mistakes.
4. design your panel. make a wireframe print. do a sanity check--lay your hardware out on the printout. do the jacks, pots, leds and switches all fit together? account for the mounting rail lip distance.
4. if you make a hole too small, you can always bore it out with a hand drill, a unibit, and a piece of wood to screw your panel into.


User avatar
consumed
International Filter Conspiracy
Posts: 3697
Joined: Fri May 25, 2007 1:38 pm
Location: nor cal

Post by consumed » Mon Aug 25, 2008 3:21 pm

the mounting holes are 0.213".
check this document out for MOTM specs:

http://synthtech.com/tech/m440_panel.pdf

User avatar
haricots
Droppin' Loads
Posts: 1501
Joined: Fri Jun 06, 2008 2:32 pm
Location: Chelsea & Cowansville, QC, Canada

Post by haricots » Tue Aug 26, 2008 9:15 am

Thanks again consumed!
